10.91 1 Introduction
1.9.2 Logging via CP315 with the SINUMERIK 840/880
1.9.2.2 Configuring the form
The form for the protocol is configured in a part program that can be edited both at work
scheduling and during manufacture.
The part program for configuring the form has the following structure:
Part 1: Description of format
Part 2: Description of fixed texts in the log header and measured value table
Description of variables in the log header
Part 3: Description of the first and last line of the table frame
Part 4: Description of the variables of the basic line of a measuring point
Description of the variables of the 1st supplementary line of a measuring point
Description of the variables of the 2nd supplementary line of a measuring point
..
..
..
Description of the variables of the 8th supplementary line of a measuring point
Part 5: End identifier
The form descriptions must be written in the part program as comments, i.e. with ”(” and ”)”.
The part program must be terminated with ”M30”.
• Part 1
In part 1, the page format is described. Part 1 consists of:
– Specification of character/line
Control character for line feed
(max. 2 bytes) Default: 10
Number of control characters for
line feed (1 or 2)
Character/line
Code: (@C
*
CC
*
ASS...S )LF
Option
– Specification of lines/page
Control character for line feed
(max. 2 bytes) Default: 12
Number of control characters for
line feed (1 or 2)
Characters per page
Code: (@L
*
LL
*
ASS...S )LF
Option
© Siemens AG 1990 All Rights Reserved 6FC5197- AB70 1–29
SINUMERIK 840/850/880 (BN)
