7 Measuring in JOG Mode (SINUMERIK 880/880 GA2) 01.93
7.2.1 Operating and function sequence
Explanation of the input values:
Tool offset
The tool offset number D...The geometry data of the workpiece probe are stored under this
tool offset number.
Workpiece probe
Number of the workpiece probe.
The number of workpiece probes depends on the
machine configuration.
(See information supplied by the machine tool
manufacturer).
Zero offset (fine)
Here you define in which zero offset memory the results of the measurement are to be stored.
Empirical value memory no.
The number of the empirical value memory to be used must be entered here.
If the value ”0” is entered the zero offset required is calculated without using an empirical
value.
If a value other than ”0” is entered the contents of the chosen empirical value memory are
displayed. This value is taken into account when the zero offset at the workpiece is calculated.
The empirical values must be entered/stored in the cycle setting data.
The number of empirical value memories depends on
the machine configuration.
(See information supplied by the machine tool
manufacturer).
Setpoint
The zero offset is determined taking the preset workpiece setpoint into consideration.
Axis names for L1/L2
The data for L1 and L2 must be assigned to axes so that the tool offset data of the workpiece
probe can be used to determine the zero offset.
7–10 ©
Siemens AG 1990 All Rights Reserved 6FC5197- AB70
SINUMERIK 840/850/880 (BN)
