3 Measuring Cycle Auxiliary Programs 08.96
3.2.2 L961 Additive input of empirical values (external)
3.2.2 L961 Additive input of empirical values (external)
*)
The number of empirical values (EV)
is determined via MDC.
(See machine tool manufacturer's specifications)
This subroutine enables a modification value to be entered in an ”Empirical value memory”
(SDC).
Transfer parameters for L961: R11 = EV memory number
R12 = Value
Example: EV is to be modified by 0.002.
Procedure:
• Select MDI mode
• R11=10 R12=0.002 L961 LF Press input key
• NC Start (without single block)
• Value of R12 is allowed for in EV memory number 10.
3.2.3 L962 Erase program EV/AV (external)
*)
The number of empirical values (EV)
is determined via MDC.
(See machine tool manufacturer's specifications)
This program serves for erasing empirical and average values (AV) in the empirical value
memory area or in the average value memory area (SDC). This may become necessary, for
instance, when changing the part program.
Transfer parameters for L962: R40 = Start address
R41 = End address
Example: The empirical value memory numbers from 20 to 30 are to be erased.
Procedure:
• Select MDI mode
• R40=20 R41=30 L962 LF Press input key
• NC Start (without single block)
• EV 20 ... 30 are erased.
• Average values 20 ... 30 are also erased if there is an average value memory.
_______
*) Version 3.0 and higher
3–4 © Siemens AG 1990 All Rights Reserved 6FC5197- AB70
SINUMERIK 840/850/880 (BN)
