Siemens SINUMERIK 840C User Manual

08.96 2 Defining Parameters
2.7.2 L973 Calibrating the workpiece probe (T)
2.7.2 L973 Calibrating the workpiece probe (T)
R23=54321
2 With arbitrary data in the plane
0 Bore
2 Surface
0 No calculation of probe ball
1 Calculation of probe ball
0/1 1 axis direction; state measuring axis and axis direction
2 2 axis direction; state measuring axis
0 No position determination
(must be selected when using a probe with 2D numbers
1 Position determination (not in the case of 1-point
measurements)
not in the case of 1-point measurement
2.7.3 L974 Workpiece measurement (T)
R23 = 0 1-point measurement (ZO determination)
21 1-point measurement
22 1-point measurement with 180° reversal (workpiece)
23 2-point measurement on diameter: external measurement with R18/R19
internal measurement without R18/R19
24 2-point measurement on diameter: internal measurement
only with R18/R19
25 Multi-point measurement on circumference
26 Multi-point measurement on cylinder
©
Siemens AG 1990 All Rights Reserved 6FC5197- AB70 2–7
SINUMERIK 840/850/880 (BN)
