10 Lists 01.93
10.4 Setting data for measuring cycles
10.4 Setting data for measuring cycles
10.4.1 Cycle setting data memory (SDC)
Empirical values and average values of the measuring cycles are stored in the cycle setting
data memory (SDC).
The SDC memory is devided in the following areas:
10.4.1.1 Channel-oriented values
Designation
SDC
No.
Standard
value
Maximum
input value
Reference
system
Input
unit
0
.
.
.
99
Siemens
(Measuring cycles)
– –––
400
.
.
.
499
User
– –––
10.4.1.2 Channel-oriented bits
SDC
No.
Bit No.
76543210
Siemens (Measuring cycles)
800
.
.
.
819
Siemens
820
.
.
.
849
User
900
.
.
.
949
10–32 © Siemens AG 1990 All Rights Reserved 6FC5197- AB70
SINUMERIK 840/850/880 (BN)
