Functions
2.16 Function Control and Circuit Breaker Test
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
239
2.16.3.3 Setting Notes
Fault Messages
Pickup of a new protection function generally turns off any previously set displays, so that only the latest fault
is displayed at any one time. It can be selected whether the stored LED displays and the spontaneous indica-
tions on the display appear upon renewed pickup, or only after a renewed trip signal is issued. In order to enter
the desired type of display, select the submenu General Device Settings in the SETTINGS menu. At address
610 FltDisp.LED/LCD the two alternatives Target on PU and Target on TRIP („No trip - no flag“) are
offered.
After startup of the device featuring a 4-line display, default measured values are displayed. Use the arrow keys
on the device front to select different measured value views to be used as the so-called default display. The
start page of the default display, which will open after each startup of the device, can be selected via parameter
640 Start image DD. The available representation types for the measured value are listed in the Appendix.
2.16.3.4 Settings
Addresses which have an appended "A" can only be changed with DIGSI, under Additional Settings.
2.16.3.5 Information List
Addr. Parameter Setting Options Default Setting Comments
610 FltDisp.LED/LCD Target on PU
Target on TRIP
Target on PU Fault Display on LED / LCD
625A T MIN LED HOLD 0 .. 60 min; ∞ 0 min Minimum hold time of lachted
LEDs
640 Start image DD image 1
image 2
image 3
image 4
image 5
image 6
image 1 Start image Default Display
No. Information Type of In-
formation
Comments
- Test mode IntSP Test mode
- DataStop IntSP Stop data transmission
- UnlockDT IntSP Unlock data transmission via BI
- Reset LED IntSP Reset LED
- SynchClock IntSP_Ev Clock Synchronization
- >Light on SP >Back Light on
- HWTestMod IntSP Hardware Test Mode
- Distur.CFC OUT Disturbance CFC
- Brk OPENED IntSP Breaker OPENED
- FdrEARTHED IntSP Feeder EARTHED
3 >Time Synch SP >Synchronize Internal Real Time Clock
5 >Reset LED SP >Reset LED
11 >Annunc. 1 SP >User defined annunciation 1
12 >Annunc. 2 SP >User defined annunciation 2
