Siemens SIPROTEC 7SD610 User Manual

Appendix
A.1 Ordering Information and Accessories
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
373
A.1.2 Accessories
Communication converter
Converter for the serial connection of the line protection system 7SD610 to synchronous communication inter-
faces X.21 G703.1 (64 kbit/s), G703–T1 (1.1455 Mbit/s), G703–E1 (2.048 Mbit/s) or symmetrical communica-
tion cables.
Name Order No.
Optical-electrical communication converter CC-X/G with synchronous interface
(X.21 / G703.1) 7XV5662-0AA00
Optical–electrical communication converter CC-CU with synchronous interface 7XV5662-0AC00
Optical-electrical communication converter CC-2M with synchronous interface
(G703-E1, G703-T1)
7XV5662-0AD00
Wide-area fibre optical repeater
Wide-area fibre optical repeater for long-distance transmission of serial signals (up to 170 km / 105.5 miles)
Name Order Number
Wide-area fibre optical repeater (24 km / 15 miles) 7XV5461-0BG00
Wide-area fibre optical repeater (60 km / 37.5 miles)
1)
7XV5461-0BH00
Wide-area fibre optical repeater (100 km / 62 miles)
1)
7XV5461-0BJ00
Wide-area fibre optical repeater (170 km / 105.5 miles)
1)
7XV5461-0BM00
Bidirectional fibre optical repeater (40 km / 25 miles)
The communication is performed via fibre-optic cables.)
2)
7XV5461-0BK00
Bidirectional fibre optical repeater (40 km / 25 miles)
The communication is performed via fibre-optic cables.)
2)
7XV5461-0BL0
1)
If wide-area fibre optical repeaters are used over distances that are below 25 km (7XV5461–0BH00) or
below 50 km (7XV5461–0BJ00) or below 100 km (7XV5461–0BM00), you have to reduce the transmitting
power using a set of optical attenuators (order number 7XV5107–0AA00). The two attenuators must be in-
stalled on one
side.
2)
A device with the order variant 7XV5461–0BK00 can only cooperate with a device of the order variant
7XV5461–0BL00.
Optical attenuators/fibre-optic cables
Designation Order number
1 set of optical attenuators (2 pcs) 7XV5107–0AA00
Fibre-optic cables
1)
6XV8100
1)
Fibre-optic cables with different connectors, in different lengths and designs. More information will be avail-
able from your local Siemens sales representative.
