Technical Data
4.1 General
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
326
4.1.4 Communication Interfaces
Protection data interfaces
Operator Interface
Service/Modem Interface (optional)
See Section 4.2 „Protection Data Interfaces and Communication Topology“
Connection Front side, non-isolated, RS232,
9-pin D-subminiature female connector for connection of a PC
Operation With DIGSI
Transmission rate Min. 4800 Baud; max. 115200 Baud;
Factory Setting: 38400 Baud; Parity: 8E1
Transmission distance 15 m / 50 feet
RS232/RS485/FO
Acc. to ordered version
Isolatede interface
for data transfer
Operation with DIGSI
RS232/RS485 RS232/RS485 according to ordered variant
Connection for flush mounting housing Rear panel, mounting location „C“,
9-pole D-subminiature female connector
Shielded data cable
For Panel Surface-Mounted Case Shielded data cable
at the terminal
at the case bottom
in console housing
at the case bottom;
9-pole D-subminiature female connector
Test Voltage 500 V; 50 Hz
transmission rate Min. 4800 Baud; max. 115200 Baud
Factory setting 38400 Baud
RS232
Maximum Distance of Transmission 15 m (50 ft)
RS485
Maximum Distance of Transmission 1,000 m (3280 ft)
