A.1 Ordering Information and Accessories
A.1.1 Ordering Information
A.1.1.1 Ordering Code (MLFB)
1)
With plug-in jumper one of the 2 voltage ranges can be selected
2)
For each binary input one of 3 pickup threshold ranges can be selected with plug-in jumper
Line Differential
Protection
7 8 9 101112 13141516
7SD610 — — + L/M/N
Measurement Input Pos. 7
I
Ph
=1 A, I
E
=1 A 1
I
Ph
=5 A, I
E
=5 A 5
Auxiliary Voltage (Power Supply, Pickup Threshold of Binary Inputs) Pos. 8
DC 24 V to 48 V, binary input threshold 19 V
2)
2
DC 60 V to 125 V
1)
, binary input threshold 19 V
2)
4
DC 110 V to 250 V
1)
, AC 115 V, binary input threshold 88 V
2)
5
DC 220 V to 250 V
1)
, AC 230 V, binary input threshold 176 V
2)
6
Mechanical Design: Housing, Number of Binary Inputs and Outputs
BI: Binary Inputs, BO: Output Relays
Pos. 9
Flush mounting housing with screwed terminals,
1
/
3
x 19”, 7 BI, 5 BO, 1 life contact B
Surface mounting housing with two-tier terminals,
1
/
3
x 19”, 7 BI, 5 BO, 1 life contact F
Flush mounting housing with plug-in terminals,
1
/
3
x 19”, with plug-in terminals, 7 BI, 5 BO, 1 life contact K
Region-specific Default / Language Settings and Function Versions Pos. 10
Region DE, 50 Hz, IEC, German language (language can be changed) A
Region: World, 50/60 Hz, IEC/ANSI, language: English (language can be changed) B
Region: USA, 60/50 Hz, ANSI, language: American English (language can be changed) C
Region: World, 50/60 Hz, IEC/ANSI, language: French (language can be changed) D
Region: World, 50/60 Hz, IEC/ANSI, language: Spanish (language can be changed) E
System Interfaces (Port B) Pos. 11
No system interface 0
IEC 60870-5-103 protocol, electrical RS232 1
IEC 60870-5-103 protocol, electrical RS485 2
IEC 60870-5-103 protocol, optical 820 nm, ST connector 3
For more interface options see Additional Specification L 9
