2.4 Breaker Intertrip and Remote Tripping
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
81
2.4.4 Information List
No. Information Type of In-
formation
Comments
3501 >Intertrip L1 SP I.Trip: >Intertrip L1 signal input
3502 >Intertrip L2 SP I.Trip: >Intertrip L2 signal input
3503 >Intertrip L3 SP I.Trip: >Intertrip L3 signal input
3504 >Intertrip 3pol SP I.Trip: >Intertrip 3 pole signal input
3505 ITrp.rec.PI1.L1 OUT I.Trip: Received at Prot.Interface 1 L1
3506 ITrp.rec.PI1.L2 OUT I.Trip: Received at Prot.Interface 1 L2
3507 ITrp.rec.PI1.L3 OUT I.Trip: Received at Prot.Interface 1 L3
3511 ITrp.sen.PI1.L1 OUT I.Trip: Sending at Prot.Interface 1 L1
3512 ITrp.sen.PI1.L2 OUT I.Trip: Sending at Prot.Interface 1 L2
3513 ITrp.sen.PI1.L3 OUT I.Trip: Sending at Prot.Interface 1 L3
3517 ITrp. Gen. TRIP OUT I.Trip: General TRIP
3518 ITrp.TRIP 1p L1 OUT I.Trip: TRIP - Only L1
3519 ITrp.TRIP 1p L2 OUT I.Trip: TRIP - Only L2
3520 ITrp.TRIP 1p L3 OUT I.Trip: TRIP - Only L3
3521 ITrp.TRIP L123 OUT I.Trip: TRIP L123
3522 ITrp.TRIP 1pole OUT I.Trip: TRIP 1pole
3523 ITrp.TRIP 3pole OUT I.Trip: TRIP 3pole
