2.1.4.3 Information List
1130A PoleOpenCurrent 1A 0.05 .. 1.00 A 0.10 A Pole Open Current
Threshold
5A 0.25 .. 5.00 A 0.50 A
1131A PoleOpenVoltage 2 .. 70 V 30 V Pole Open Voltage
Threshold
1132A SI Time all Cl. 0.01 .. 30.00 sec 0.10 sec Seal-in Time after ALL clo-
sures
1133A T DELAY SOTF 0.05 .. 30.00 sec 0.25 sec minimal time for line open
before SOTF
1134 Line Closure only with ManCl
I OR U or ManCl
CB OR I or M/C
I or Man.Close
I or Man.Close Recognition of Line Clo-
sures with
1135 Reset Trip CMD CurrentOpenPole
Current AND CB
Pickup Reset
CurrentOpenPole RESET of Trip Command
1136 OpenPoleDetect. OFF
Current AND CB
w/ measurement
w/ measurement open pole detector
1150A SI Time Man.Cl 0.01 .. 30.00 sec 0.30 sec Seal-in Time after
MANUAL closures
1151 SYN.MAN.CL w/o Sync-check
NO
NO Manual CLOSE
COMMAND generation
1152 Man.Clos. Imp. (Setting options depend
on configuration)
None MANUAL Closure Impulse
after CONTROL
1155 3pole coupling with PICKUP
with TRIP
with TRIP 3 pole coupling
1156A Trip2phFlt 3pole
1pole leading Ø
1pole lagging Ø
3pole Trip type with 2phase
faults
1161 VECTOR GROUP U 0 .. 11 0 Vector group numeral for
voltage
1162 VECTOR GROUP I 0 .. 11 0 Vector group numeral for
current
1163 TRANS STP IS Solid Earthed
Not Earthed
Solid Earthed Transformer starpoint is
No. Information Type of In-
formation
Comments
301 Pow.Sys.Flt. OUT Power System fault
302 Fault Event OUT Fault Event
351 >CB Aux. L1 SP >Circuit breaker aux. contact: Pole L1
352 >CB Aux. L2 SP >Circuit breaker aux. contact: Pole L2
353 >CB Aux. L3 SP >Circuit breaker aux. contact: Pole L3
356 >Manual Close SP >Manual close signal
Addr. Parameter C Setting Options Default Setting Comments
