Appendix
A.4 Default Settings
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
382
A.4 Default Settings
A.4.1 LEDs
Table A-1 LED Indication Presettings
A.4.2 Binary Input
Table A-2 Binary input presettings for all devices and ordering variants
A.4.3 Binary Output
Table A-3 Output relay presettings for all devices and ordering variants
LEDs Allocated Func-
tion
Function No. Description
LED1 Relay TRIP 511 Relay GENERAL TRIP command
LED2 Relay PICKUP L1 503 Relay PICKUP Phase L1
LED3 Relay PICKUP L2 504 Relay PICKUP Phase L2
LED4 Relay PICKUP L3 505 Relay PICKUP Phase L3
LED5 Par. different 3235 Differences between common parameters
LED6 PI1 Data fault 3229 Prot Int 1: Reception of faulty data
LED7 DT inconsistent 3233 Device table has inconsistent numbers
DT unequal 3234 Device tables are unequal
Equal IDs 3487 Equal IDs in constellation
Binary Input Allocated Func-
tion
Function No. Description
BI1 >Intertrip 3pol 3504 I.Trip: >Intertrip 3 pole signal input
BI2 >Reset LED 5 >Reset LED
BI3 > Diff block 3525 >Differential protection blocking signal
BI4 >DTT Trip L123 4417 >Direct Transfer Trip INPUT 3ph L123
BI5 >BLOCK O/C I>> 7104 >BLOCK Backup OverCurrent I>>
>BLOCK O/C I> 7105 >BLOCK Backup OverCurrent I>
>BLOCK O/C Ip 7106 >BLOCK Backup OverCurrent Ip
>BLOCK O/C Ie>> 7107 >BLOCK Backup OverCurrent Ie>>
>BLOCK O/C Ie> 7108 >BLOCK Backup OverCurrent Ie>
>BLOCK O/C Iep 7109 >BLOCK Backup OverCurrent Iep
>BLOCK I-STUB 7130 >BLOCK I-STUB
>BLOCK O/CIe>>> 7132 >BLOCK Backup OverCurrent Ie>>>
>BLOCK Dir. I> 7111 >BLOCK direct. Backup OverCurrent I>
>BLOCK Dir. Ip 7112 >BLOCK direct. Backup OverCurrent Ip
BI7 >CB1 Ready 371 >CB1 READY (for AR,CB-Test)
Binary Output Allocated Func-
tion
Function No. Description
BO1 Relay PICKUP L1 503 Relay PICKUP Phase L1
BO2 Relay PICKUP L2 504 Relay PICKUP Phase L2
BO3 Relay PICKUP L3 505 Relay PICKUP Phase L3
BO4 Relay TRIP 511 Relay GENERAL TRIP command
BO5 Relay TRIP 511 Relay GENERAL TRIP command
