Siemens SIPROTEC 7SD610 User Manual

Functions
2.16 Function Control and Circuit Breaker Test
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
241
2.16.4 EN100-Module
2.16.4.1 Function Description
An EN100-Module allows to integrate the 7SD610 into 100 Mbit communication networks used by process
control and automation systems in accordance with IEC 61850. This standard provides consistent inter-relay
communication without gateways or protocol converters. This allows open and interoperable use of
SIPROTEC 4 devices even in heterogeneous environments. In parallel to the process control integration of the
device, this interface can also be used for communication with DIGSI and for inter-relay communication via
GOOSE.
2.16.4.2 Setting Notes
Interface Selection
No settings are required for operation of the Ethernet system interface module (IEC 61850 EN100-Modul 1).
If the device is equipped with such a module (see MLFB), the module is automatically configured to the inter-
face available for it, namely Port B.
2.16.4.3 Information List
No. Information Type of In-
formation
Comments
009.0100 Failure Modul IntSP Failure EN100 Modul
009.0101 Fail Ch1 IntSP Failure EN100 Link Channel 1 (Ch1)
009.0102 Fail Ch2 IntSP Failure EN100 Link Channel 2 (Ch2)
