Appendix
A.6 Functional Scope
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
386
A.6 Functional Scope
Addr. Parameter Setting Options Default Setting Comments
103 Grp Chge OPTION Disabled
Enabled
Disabled Setting Group Change Option
110 Trip mode 3pole only
1-/3pole
3pole only Trip mode
112 DIFF.PROTECTION Enabled
Disabled
Enabled Differential protection
122 DTT Direct Trip Disabled
Enabled
Disabled DTT Direct Transfer Trip
124 HS/SOTF-O/C Disabled
Enabled
Disabled Instantaneous HighSpeed/SOTF
Overcurrent
126 Back-Up O/C Disabled
TOC IEC
TOC ANSI
TOC IEC Backup overcurrent
133 Auto Reclose 1 AR-cycle
2 AR-cycles
3 AR-cycles
4 AR-cycles
5 AR-cycles
6 AR-cycles
7 AR-cycles
8 AR-cycles
ADT
Disabled
Disabled Auto-Reclose Function
134 AR control mode Pickup w/ Tact
Pickup w/o Tact
Trip w/ Tact
Trip w/o Tact
Trip w/o Tact Auto-Reclose control mode
136 FREQUENCY Prot. Disabled
Enabled
Disabled Over / Underfrequency Protection
137 U/O VOLTAGE Disabled
Enabled
Enabl. w. comp.
Disabled Under / Overvoltage Protection
139 BREAKER FAILURE Disabled
Enabled
enabled w/ 3I0>
Disabled Breaker Failure Protection
140 Trip Cir. Sup. Disabled
1 trip circuit
2 trip circuits
3 trip circuits
Disabled Trip Circuit Supervision
141 REF PROT. Disabled
Enabled
Disabled Restricted earth fault protection
142 Therm.Overload Disabled
Enabled
Disabled Thermal Overload Protection
143 TRANSFORMER NO
YES
NO Transformer inside protection
zone
144 V-TRANSFORMER Not connected
connected
connected Voltage transformers
148 GPS-SYNC. Enabled
Disabled
Disabled GPS synchronization
