Functions
2.2 Protection Data Interfaces and Protection Data Topology
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
62
2.2.3.3 Information List
4509 T-DATA DISTURB 0.05 .. 2.00 sec 0.10 sec Time delay for data disturbance
alarm
4510 T-DATAFAIL 0.0 .. 60.0 sec 6.0 sec Time del for transmission failure
alarm
4511 PI1 SYNCMODE TEL and GPS
TEL or GPS
GPS SYNC OFF
TEL and GPS PI1 Synchronizationmode
4512 Td ResetRemote 0.00 .. 300.00 sec; ∞ 0.00 sec Remote signal RESET DELAY for
comm.fail
4513A PROT1 max ERROR 0.5 .. 20.0 % 1.0 % Prot 1: Maximal permissible error
rate
4515A PI1 BLOCK UNSYM YES
NO
YES Prot.1: Block. due to unsym. delay
time
4801 GPS-SYNC. ON
OFF
OFF GPS synchronization
4803A TD GPS FAILD 0.5 .. 60.0 sec 2.1 sec Delay time for local GPS-pulse
loss
No. Information Type of In-
formation
Comments
3215 Wrong Firmware OUT Incompatible Firmware Versions
3217 PI1 Data reflec OUT Prot Int 1: Own Datas received
3227 >PI1 light off SP >Prot Int 1: Transmitter is switched off
3229 PI1 Data fault OUT Prot Int 1: Reception of faulty data
3230 PI1 Datafailure OUT Prot Int 1: Total receiption failure
3233 DT inconsistent OUT Device table has inconsistent numbers
3234 DT unequal OUT Device tables are unequal
3235 Par. different OUT Differences between common parameters
3239 PI1 TD alarm OUT Prot Int 1: Transmission delay too high
3243 PI1 with VI Prot Int 1: Connected with relay ID
3245 >GPS failure SP > GPS failure from external
3247 GPS loss OUT GPS: local pulse loss
3248 PI 1 GPS sync. OUT GPS: Prot Int 1 is GPS sychronized
3250 PI 1 PD unsym. OUT GPS:PI1 unsym.propagation delay too high
3252 >SYNC PI1 RESET SP > PI1 Synchronization RESET
3254 PI1 jump OUT Prot.1: Delay time change recognized
3256 PI1 unsym. IntSP Prot.1: Delay time unsymmetry to large
3258 PI1 Error OUT ProtInt1:Permissible error rate exceeded
3274 PI1: C37.94 n/a OUT PI1: IEEE C37.94 not supported by module
Addr. Parameter Setting Options Default Setting Comments
