Functions
2.14 Automatic Reclosing System 79
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
272
2.14.8 Information List
7247 bef.4.Cy:67NTOC Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 67N TOC
7248 bef.1.Cy:50-3 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 50-3
7249 bef.1.Cy:50N-3 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 50N-3
7250 bef.2.Cy:50-3 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 2. Cycle: 50-3
7251 bef.2.Cy:50N-3 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 2. Cycle: 50N-3
7252 bef.3.Cy:50-3 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 3. Cycle: 50-3
7253 bef.3.Cy:50N-3 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 3. Cycle: 50N-3
7254 bef.4.Cy:50-3 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 50-3
7255 bef.4.Cy:50N-3 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 50N-3
No. Information Type of In-
formation
Comments
127 79 ON/OFF IntSP 79 ON/OFF (via system port)
2701 >79 ON SP >79 ON
2702 >79 OFF SP >79 OFF
2703 >BLOCK 79 SP >BLOCK 79
2711 >79 Start SP >79 External start of internal A/R
2715 >Start 79 Gnd SP >Start 79 Ground program
2716 >Start 79 Ph SP >Start 79 Phase program
2722 >ZSC ON SP >Switch zone sequence coordination ON
2723 >ZSC OFF SP >Switch zone sequence coordination OFF
2730 >CB Ready SP >Circuit breaker READY for reclosing
2731 >Sync.release SP >79: Sync. release from ext. sync.-check
2753 79 DT delay ex. OUT 79: Max. Dead Time Start Delay expired
2754 >79 DT St.Delay SP >79: Dead Time Start Delay
2781 79 OFF OUT 79 Auto recloser is switched OFF
2782 79 ON IntSP 79 Auto recloser is switched ON
Addr. Parameter Setting Options Default Setting Comments
