2.17 Flexible Protection Functions
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
295
2.17.4 Information List
No. Information Type of In-
formation
Comments
235.2110 >BLOCK $00 SP >BLOCK Function $00
235.2111 >$00 instant. SP >Function $00 instantaneous TRIP
235.2112 >$00 Dir.TRIP SP >Function $00 Direct TRIP
235.2113 >$00 BLK.TDly SP >Function $00 BLOCK TRIP Time Delay
235.2114 >$00 BLK.TRIP SP >Function $00 BLOCK TRIP
235.2115 >$00 BL.TripA SP >Function $00 BLOCK TRIP Phase A
235.2116 >$00 BL.TripB SP >Function $00 BLOCK TRIP Phase B
235.2117 >$00 BL.TripC SP >Function $00 BLOCK TRIP Phase C
235.2118 $00 BLOCKED OUT Function $00 is BLOCKED
235.2119 $00 OFF OUT Function $00 is switched OFF
235.2120 $00 ACTIVE OUT Function $00 is ACTIVE
235.2121 $00 picked up OUT Function $00 picked up
235.2122 $00 pickup A OUT Function $00 Pickup Phase A
235.2123 $00 pickup B OUT Function $00 Pickup Phase B
235.2124 $00 pickup C OUT Function $00 Pickup Phase C
235.2125 $00 Time Out OUT Function $00 TRIP Delay Time Out
235.2126 $00 TRIP OUT Function $00 TRIP
236.2127 BLK. Flex.Fct. IntSP BLOCK Flexible Function
235.2128 $00 inval.set OUT Function $00 has invalid settings
