A.7 Functional Scope
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
626
A.7 Functional Scope
Addr. Parameter Setting Options Default Setting Comments
103 Grp Chge OPTION Disabled
Enabled
Disabled Setting Group Change Option
104 OSC. FAULT REC. Disabled
Enabled
Enabled Oscillographic Fault Records
112 Charac. Phase Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
Definite Time 50/51
113 Charac. Ground Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
Definite Time 50N/51N
115 67/67-TOC Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
Definite Time 67, 67-TOC
116 67N/67N-TOC Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
Definite Time 67N, 67N-TOC
117 Coldload Pickup Disabled
Enabled
Disabled Cold Load Pickup
122 InrushRestraint Disabled
Enabled
Disabled 2nd Harmonic Inrush Restraint
127 50 1Ph Disabled
Enabled
Disabled 50 1Ph
130 S.Gnd.F.Dir.Ch cos ϕ / sin ϕ
V0/I0 ϕ mea.
cos ϕ / sin ϕ (sens.) Ground fault dir. character-
istic
131 Sens. Gnd Fault Disabled
Definite Time
User Defined PU
Log. inverse A
Log. Inverse B
Disabled (sensitive) Ground fault
133 INTERM.EF Disabled
with Ignd
with 3I0
with Ignd,sens.
Disabled Intermittent earth fault protection
140 46 Disabled
TOC ANSI
TOC IEC
Definite Time
Disabled 46 Negative Sequence Protection
141 48 Disabled
Enabled
Disabled 48 Startup Supervision of Motors
