Functions
2.1 General
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
54
2.1.4.4 Information List
2.1.5 Settings Groups
Up to four different setting groups can be created for establishing the device's function settings.
Applications
• Setting groups enable the user to save the corresponding settings for each application so that they can be
quickly called up when required. All setting groups are stored in the device. Only one setting group may be
active at a time.
2.1.5.1 Description
Changing Setting Groups
During operation the user can switch back and forth setting groups locally, via the operator panel, binary inputs
(if so configured), the service interface using a personal computer, or via the system interface. For reasons of
safety it is not possible to change between setting groups during a power system fault.
A setting group includes the setting values for all functions that have been selected as Enabled during con-
figuration (see Section 2.1.1.2). In 7SJ62/64 relays, four independent setting groups (A to D) are available.
While setting values may vary, the selected functions of each setting group remain the same.
2.1.5.2 Setting Notes
General
If setting group change option is not required, Group A is the default selection. Then, the rest of this section is
not applicable.
If the changeover option is desired, group changeover must be set to Grp Chge OPTION = Enabled (address
103) when the function extent is configured. For the setting of the function parameters, each of the required
setting groups A to D (a maximum of 4) must be configured in sequence. The SIPROTEC 4 System Description
gives further information on how to copy setting groups or reset them to their status at delivery and also how
to change from one setting group to another.
Subsection 3.1 of this manual tells you how to change between several setting groups externally via binary
inputs.
No. Information Type of In-
formation
Comments
- FltRecSta IntSP Fault Recording Start
4 >Trig.Wave.Cap. SP >Trigger Waveform Capture
203 Wave. deleted OUT_Ev Waveform data deleted
30053 Fault rec. run. OUT Fault recording is running
www . ElectricalPartManuals . com
