Appendix
A.1 Ordering Information and Accessories
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
553
A.1.1.2 7SJ64 V4.7
1)
230 VAC only possible with release 7SJ64**...../CC and higher
Multi-Functional
Protective Relay with
Local Control
6 7 8 9 10 11 12 13 14 15 16 Supplemen-
tary
7SJ64 ––+
Housing, Inputs and Outputs, Measuring Transducer Pos. 6
Housing
1
/
3
19'', 4-line Display, 7 BI, 5 BO, 1 Live Status Contact; 9th position only with: B, D, E 0
Housing
1
/
2
19'', Graphic Display, 15 BI, 13 BO, 1 Live Status Contact 1
Housing
1
/
2
19'', Graphic Display, 20 BI, 8 BO, 2 High-duty relays (4 Contacts), 1 Live Status Contact 2
Housing
1
/
1
19'', Graphic Display, 33 BI, 11 BO, 4 High-duty relays (8 Contacts), 1 Live Status Contact 5
Housing
1
/
1
19'', Graphic Display, 48 BI, 21 BO, 4 High-duty relays (8 Contacts), 1 Live Status Contact 7
Measuring Inputs (4 x V, 4 x I)Pos. 7
I
Ph
= 1 A, I
N
= 1 A (min. = 0.05 A); 15th position only with A, C, E, G 1
I
Ph
= 1 A, I
N
= sensitive (min. = 0.001 A); 15th position only with B, D, F, H 2
I
Ph
= 5 A, I
N
= 5 A (min. = 0.25 A); 15th position only with A, C, E, G 5
I
Ph
= 5 A, I
N
= sensitive (min. = 0.001 A); 15th position only with B, D, F, H 6
I
Ph
= 5 A, I
N
= 1 A (min. = 0.05 A); 15th position only with A, C, E, G 7
Power Supply, Binary Input Pickup Threshold Setting Pos. 8
24 to 48 VDC, Binary Input Threshold 19 VDC 2
60 to 125 VDC, Binary Input Threshold 19 VDC 4
110 to 250 VDC, 115 to 230 VAC
1)
, Binary Input Threshold 88 VDC 5
Construction Pos. 9
Surface-mounting case, plug-in terminals, detached operator panel Installation in a low-voltage compartment A
Surface-mounting case for panel, 2 tier terminals top/bottom B
Surface-mounting case, screw-type terminals (direct connection / ring and spade lugs), detached operator
panel, installation in a low-voltage
C
Flush mounting case with plug-in terminals (2/3 pin connector) D
Flush mounting case, screw-type terminals (direct connection / ring and spade lugs) E
Surface-mounting case, screw-type terminals (direct connection / ring and spade lugs), without operator panel,
installation in a low-voltage
F
Surface-mounting case, plug-in terminals, without operator panel Installation in a low-voltage compartment G
Region-specific Default / Language Settings and Function Versions Pos. 10
Region DE, 50 Hz, IEC, Language German (Language can be changed) A
Region World, 50/60 Hz, IEC/ANSI, language English (language can be changed) B
Region US, 60 Hz, ANSI/IEC, Language American English (Language can be changed) C
Region FR, 50/60 Hz, IEC/ANSI, Language French (Language can be changed) D
Region World, 50/60 Hz, IEC/ANSI, Language Spanish (Language can be changed) E
Region World, 50/60 Hz, IEC/ANSI, Language Italian (Language can be changed) F
