Technical Data
4.27 Dimensions
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
544
4.27.8
Housing for Mounting wi
th Det
ached Operator Pa
nel or without Operator
Panel (Housi
ng Size
1
/
1
)
Figure
4-20
Dimensions 7SJ64 for
mounting with detached op
erator panel or without operator panel (housing size
1
/
1
)
