Siemens SIPROTEC 7SJ62 User Manual

Appendix
A.11 Measured Values
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
683
A.11 Measured Values
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
- I A dmd> (I Admd>) Set Points(MV) - - - - - CFC CD DD
- I B dmd> (I Bdmd>) Set Points(MV) - - - - - CFC CD DD
- I C dmd> (I Cdmd>) Set Points(MV) - - - - - CFC CD DD
- I1dmd> (I1dmd>) Set Points(MV) - - - - - CFC CD DD
- |Pdmd|> (|Pdmd|>) Set Points(MV) - - - - - CFC CD DD
- |Qdmd|> (|Qdmd|>) Set Points(MV) - - - - - CFC CD DD
- |Sdmd|> (|Sdmd|>) Set Points(MV) - - - - - CFC CD DD
- Pressure< (Press<) Set Points(MV) - - - - - CFC CD DD
- Temp> (Temp>) Set Points(MV) - - - - - CFC CD DD
- 37-1 under current (37-1) Set Points(MV) - - - - - CFC CD DD
- |Power Factor|< (|PF|<) Set Points(MV) - - - - - CFC CD DD
- Number of TRIPs= (#of TRIPs=) Statistics - - - - - CFC CD DD
- Operating hours greater than (OpHour>) SetPoint(Stat) - - - - - CFC CD DD
170.2050 V1 = (V1 =) SYNC function 1 130 1 No 9 1 CFC CD DD
170.2050 V1 = (V1 =) SYNC function 2 130 2 No 9 1 CFC CD DD
170.2050 V1 = (V1 =) SYNC function 3 130 3 No 9 1 CFC CD DD
170.2050 V1 = (V1 =) SYNC function 4 130 4 No 9 1 CFC CD DD
170.2051 f1 = (f1 =) SYNC function 1 130 1 No 9 4 CFC CD DD
170.2051 f1 = (f1 =) SYNC function 2 130 2 No 9 4 CFC CD DD
170.2051 f1 = (f1 =) SYNC function 3 130 3 No 9 4 CFC CD DD
170.2051 f1 = (f1 =) SYNC function 4 130 4 No 9 4 CFC CD DD
170.2052 V2 = (V2 =) SYNC function 1 130 1 No 9 3 CFC CD DD
170.2052 V2 = (V2 =) SYNC function 2 130 2 No 9 3 CFC CD DD
170.2052 V2 = (V2 =) SYNC function 3 130 3 No 9 3 CFC CD DD
170.2052 V2 = (V2 =) SYNC function 4 130 4 No 9 3 CFC CD DD
170.2053 f2 = (f2 =) SYNC function 1 130 1 No 9 7 CFC CD DD
170.2053 f2 = (f2 =) SYNC function 2 130 2 No 9 7 CFC CD DD
170.2053 f2 = (f2 =) SYNC function 3 130 3 No 9 7 CFC CD DD
170.2053 f2 = (f2 =) SYNC function 4 130 4 No 9 7 CFC CD DD
170.2054 dV = (dV =) SYNC function 1 130 1 No 9 2 CFC CD DD
170.2054 dV = (dV =) SYNC function 2 130 2 No 9 2 CFC CD DD
170.2054 dV = (dV =) SYNC function 3 130 3 No 9 2 CFC CD DD
170.2054 dV = (dV =) SYNC function 4 130 4 No 9 2 CFC CD DD
170.2055 df = (df =) SYNC function 1 130 1 No 9 5 CFC CD DD
170.2055 df = (df =) SYNC function 2 130 2 No 9 5 CFC CD DD
170.2055 df = (df =) SYNC function 3 130 3 No 9 5 CFC CD DD
170.2055 df = (df =) SYNC function 4 130 4 No 9 5 CFC CD DD
170.2056 dalpha = (dα =) SYNC function 1 130 1 No 9 6 CFC CD DD
170.2056 dalpha = (dα =) SYNC function 2 130 2 No 9 6 CFC CD DD
170.2056 dalpha = (dα =) SYNC function 3 130 3 No 9 6 CFC CD DD
170.2056 dalpha = (dα =) SYNC function 4 130 4 No 9 6 CFC CD DD
601 Ia (Ia =) Measurement 134 137 No 9 1 CFC CD DD
602 Ib (Ib =) Measurement 160 145 Yes 3 1 CFC CD DD
134 137 No 9 2
