2.19 Synchronization Function
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
322
170.2027 25 V1> V2< OUT 25 Condition V1>V2< fulfilled
170.2028 25 V1< V2> OUT 25 Condition V1<V2> fulfilled
170.2029 25 V1< V2< OUT 25 Condition V1<V2< fulfilled
170.2030 25 Vdiff ok OUT 25 Voltage difference (Vdiff) okay
170.2031 25 fdiff ok OUT 25 Frequency difference (fdiff) okay
170.2032 25 αdiff ok OUT 25 Angle difference (alphadiff) okay
170.2033 25 f1>> OUT 25 Frequency f1 > fmax permissible
170.2034 25 f1<< OUT 25 Frequency f1 < fmin permissible
170.2035 25 f2>> OUT 25 Frequency f2 > fmax permissible
170.2036 25 f2<< OUT 25 Frequency f2 < fmin permissible
170.2037 25 V1>> OUT 25 Voltage V1 > Vmax permissible
170.2038 25 V1<< OUT 25 Voltage V1 < Vmin permissible
170.2039 25 V2>> OUT 25 Voltage V2 > Vmax permissible
170.2040 25 V2<< OUT 25 Voltage V2 < Vmin permissible
170.2050 V1 = MV V1 =
170.2051 f1 = MV f1 =
170.2052 V2 = MV V2 =
170.2053 f2 = MV f2 =
170.2054 dV = MV dV =
170.2055 df = MV df =
170.2056 dα = MV dalpha =
170.2090 25 V2>V1 OUT 25 Vdiff too large (V2>V1)
170.2091 25 V2<V1 OUT 25 Vdiff too large (V2<V1)
170.2092 25 f2>f1 OUT 25 fdiff too large (f2>f1)
170.2093 25 f2<f1 OUT 25 fdiff too large (f2<f1)
170.2094 25 α2>α1 OUT 25 alphadiff too large (a2>a1)
170.2095 25 α2<α1 OUT 25 alphadiff too large (a2<a1)
170.2096 25 FG-Error OUT 25 Multiple selection of func-groups
170.2097 25 Set-Error OUT 25 Setting error
170.2101 25-1 OFF OUT Sync-group 1 is switched OFF
170.2102 >BLK 25 CLOSE SP >BLOCK 25 CLOSE command
170.2103 25 CLOSE BLK OUT 25 CLOSE command is BLOCKED
170.2332 Sync f syn OUT Sync:Synchronization cond. f syn
No. Information Type of In-
formation
Comments
