A5E32106153 SITRANS Probe LR – AVVIO RAPIDO Pagina IT-3
mmmmm
Italiano
Alimentazione
• Massima 30 V CC
• da 4 a 20 mA
Certificazioni
• Generali CSA
US/C
, FM, CE, C-TICK
• Radio Europa (R&TTE), FCC, Industry Canada
• Zone a rischio
Intrinsecamente sicuro (Europa) ATEX II 1 G EEx ia IIC T4
(US/Canada) FM/CSA
1
: (richiede isolamento)
Classe I, Div. 1, Gruppi A, B, C, D
Classe II, Div. 1, Gruppi E, F, G
Classe III T4
(Australia) ANZEx Ex ia IIC T4
(Tamb = da -40 a +80 °C) IP67, IP68
(Internazionale) IECEx TSA 04.0020X Ex ia IIC T4
(Brazil) INMETRO: DNV 12.0068 X
Ex ia IIC T4 Ga
IP66/IP67/IP68
-40 ºC
≤ T a ≤ +80 ºC
DNV #OCP 0017
ABNT NBR IEC 60079-0:2008 e
ABNT NBR IEC 60079-11:2009
Non incendiario (US) FM
2
:
Classe I, Div. 2, Gruppi A, B, C, DT5
• Marittima Lloyd’s Register of Shipping
Certificazione ABS (American Bureau of Shipping)
Caratteristiche meccaniche
• Attacchi al processo:
raccordo filettato 1.5” NPT, BSP, o G (BS EN ISO 228-1)
•Antenna:
asta di polipropilene costruzione sigillata ermeticamente
Nominale 24 V CC a 550 Ohm max.
1.
Vedi Wiring Drawing: Intrinsically Safe (FM ) pagina 2, Appendice A, illustrazione n. 23651611, o
Wiring Drawing: Intrinsically Safe (CSA) pagina 3, Appendice A, illustrazione n. 23651621.
2.
Vedi Wiring Drawing: Non-incendive (FM) pagina 1, Appendice A, illustrazione n. 23650537.
Nota: Si richiede l'uso di guarnizioni/tenute protettive stagne certificate per applicazioni
esterne Type 4X / NEMA 4X, Type 6 / NEMA 6, IP67, IP68.
Nota: il SITRANS Probe LR è stato installato su un serbatoio metallico e verificato in
conformità con la norma EN61000-4-3 (CEM CE).
