A: Connection Drawings
Appendix A: Connection Drawings and Loop
Power Curve
Wiring Drawing: Non-incendive (FM)
Note: Reference drawing 23650537 is available from the SITRANS Probe LR product page of
our website at: https://pia.khe.siemens.com/index.asp?Nr=11158
.
Product Group
FOR INTERNAL
USE ONLY
2365053701
S. NGUYEN
PETERBOROUGH
05 / MAR / 2004
RADAR
FOR CONSTRUCTION
REMOVE NON- FROM HAZARDOUS SIDE
PER ECN 2004-0113
0
1
T. LITTLE
R. CLYSDALE
1:1
1
1
NTS
A
SITRANS LR 200 / PROBE LR
CLASS I, Div. 2
CONNECTION DRAWING
23650537
1
RPC
RPC
SN
SN
MAR
05/2004
MAY
03/2004
NON-HAZARDOUS LOCATION
(SAFE)
HAZARDOUS LOCATION
CLASS I, DIV.2, GROUPS A, B, C, D
24 V
POWER
SUPPLY
SITRANS LR 200/
SITRANS Probe LR
1/2 “ NPT
NOTES:
1) INSTALLATION SHALL BE DONE IN ACCORDANCE WITH THE
NATIONAL ELECTRICAL CODE.
2) USE APPROVED WATER TIGHT CONDUIT FITTINGS FOR OUTDOOR APPLICATIONS.
3) FOR FURTHER INFORMATION REFER TO THE
SITRANS LR 200 / Probe LR INSTRUCTION MANUAL
