5 Repairing optical fibres
⇒ p5.1 oints”, page 96
⇒ o5.2 ptical fibres”, page 96
⇒ a5.3 nd installing optical fibre in the housing”, page 102
5.1 General points
The exact point of failure is very hard to find. The damaged
optical fibre must be replaced by laying a line parallel to the
defective optical fibre.
Note
♦
The "Targeted fault-finding" or "Targeted functions" menu
items on the vehicle diagnostic tester can be used to de‐
termine the components between which the optical fibre is
damaged.
♦
An optical fibre that has already been repaired is "yellow".
Method for preparing and laying a new optical fibre.
Caution
Optical fibres must not have any sharp kinks. The minimum
bending radius must not be less than 25 mm.
Optical fibres must not be laid over sharp edges.
The end of optical fibres must not be dirty or touched with
bare fingers.
Optical fibres must not be heated.
You must not twist together two optical fibres or one optical
fibre with a copper wire.
Protect the connector and connection cable against dirt. Use
protective caps from the case.
5.2 Preparing optical fibres
Special tools and workshop equipment required
♦ Optical fibre repair set -VAS 6223B-
Caution
Optical fibres must not have any sharp kinks. The minimum
bending radius must not be less than 25 mm.
Optical fibres must not be laid over sharp edges.
The end of optical fibres must not be dirty or touched with
bare fingers.
Optical fibres must not be heated.
You must not twist together two optical fibres or one optical
fibre with a copper wire.
Protect the connector and connection cable against dirt. Use
protective caps from the case.
Citigo 2012 ➤, Citigo-e iV 2020 ➤, Enyaq 2021 ➤, Enyaq Coupe 2021 ➤, Fabia 2000 ...
Electrical System - general notes - Edition 12.2021
96 Rep. gr.97 - Wiring
