2 Wiring harness repair
⇒ i2.1 nstructions for the repair on the vehicle electrics”, page
41
⇒ i2.2 nstructions for wiring harness and plug repair ”, page 42
⇒ d2.3 escriptions”, page 43
⇒ o2.4 f airbag and belt tensioner cables”, page 48
⇒ o2.5 f CAN bus lines”, page 50
⇒ n2.6 ew contacts”, page 51
⇒ o2.7 f 0.13 mm2/ 0.35 mm2/ 0.5 mm2 cable”, page 54
⇒ a2.8 10 mm2- or 16 mm2 cable with an individual joint butt
splice connector”, page 59
⇒ b2.9 reak with single repair point”, page 66
⇒ b2.10 reak with two repair points”, page 69
⇒ a2.11 erial cables”, page 72
2.1 General instructions for the repair on
the vehicle electrics
WARNING
♦ Pay attention to the stickers affixed to the vehicle which
indicate components with high voltage. The remaining
voltage must be discharged when undertaking repair
work (e.g. switch the electrical component on and off
again after disconnecting the battery).
♦ Some tools have a tool locking element which must be
pushed over the tip of the tool after use, in order to
protect the employee from injury and the tool tip from
damage.
Caution
♦ When disconnecting and connecting the battery, respect
the specified procedure ⇒ Electrical System; Rep. gr. 27.
♦ Before starting a repair, it is absolutely necessary to
eliminate the cause of the damage (e.g. sharp-edged
body parts, defective electrical components, corrosion
etc.).
♦ When carrying out repairs, observe the current instructions
in the relevant Workshop Manuals.
♦ If possible, do not loosen any earth straps from the body
(risk of corrosion).
♦ When carrying out repairs, observe the current instructions
in the relevant Workshop Manuals.
♦ Country-specific regulations must be observed.
Citigo 2012 ➤, Citigo-e iV 2020 ➤, Enyaq 2021 ➤, Enyaq Coupe 2021 ➤, Fabia 2000 ...
Electrical System - general notes - Edition 12.2021
2. Wiring harness repair 41
