2.5 Battery tester with printer -VAS 6161-
⇒ d2.5.1 escription”, page 12
⇒ b2.5.2 attery test with the battery tester with printerVAS
6161”, page 13
⇒ o2.5.3 f a VW original battery”, page 14
⇒ s2.5.5 hould be taken when storing”, page 15
⇒ o2.5.4 f a non -VW battery:”, page 15
⇒ r2.5.6 egarding the test printout”, page 16
⇒ r2.5.7 esult assessment”, page 16
2.5.1 General description
WARNING
♦ There is a risk of accident when working on the battery.
Observe the warning instructions and safety precautions
⇒ i1.3 nstructions and safety precautions when working
on the battery”, page 4 .
♦ Carefully read through the Owner's Manual and observe
during the measurement before using the battery tester.
When using the battery tester with printer -VAS 6161-, the bat‐
tery must not be disconnected or removed.
The battery tester with printer -VAS 6161- does not stress the
battery. It operates on the principle of dynamic conductivity de‐
tection.
All types of batteries are stored in the tester.
The data can be stored on a SD card.
The battery tester with printer -VAS 6161- can be updated via
an interface or the SD card.
The integrated temperature sender improves the measurement
quality.
Device description battery tester with printer -VAS 6161-
1 - integrated printer
Citigo 2012 ➤, Citigo-e iV 2020 ➤, Enyaq 2021 ➤, Enyaq Coupe 2021 ➤, Fabia 2000 ...
Electrical System - general notes - Edition 12.2021
12 Rep. gr.27 - Starter, current supply, CCS
