NOTICE
There is a risk of damage to the mechatronics for double
clutch gearbox -J743-.
• Only the hydraulic oil available as a spare part may be
used for the Mechatronics for dual-clutch gearbox -J743-
⇒ Electronic Catalogue of Original Parts.
Other hydraulic oils lead to malfunctions and/or gearbox fail‐
ure.
The hydraulic oil level cannot be checked.
In the case of loss of hydraulic oil from mechatronics, the
correct oil level can only be adjusted by draining the old oil
and filling up with new oil ⇒ a7.2 nd top up hydraulic oil for
mechatronics”, page 233 .
• During assembly work, the mechatronics must be sealed
oil-tight ⇒ Fig. ““Close the gearbox in an oil-tight manner”“,
page 225 .
An insufficient amount of hydraulic oil and overfilling affect the
function of the mechatronics, this can lead to malfunctions.
4.2 Allocation gearbox - engine
⇒ g4.2.1 earbox - engine Octavia III”, page 12
⇒ g4.2.2 earbox - engine Rapid”, page 13
4.2.1 Assignment gearbox - engine Octavia III
Vehicles with petrol engines, front-wheel drive
7-speed dual-clutch gearbox DSG - 0CW
Front-wheel-drive
Vehicles with petrol
engines
Gearbox identification characters
1.0 l/85 kW TSI QGM SML TSV
RQL SST UBT
1.2 l/77 kW TSI NNN PWM QHV
PNA PYT QSA
PLE QRL
1.2 l/81 kW TSI QHV QXM
QSA RES
1.4 ltr./103 kW TSI MSP PYU QXN
PNB QRM RET
PLF QHW
PWN QSB
1.4 ltr./110 kW TSI QRM RET SSM
QHW RWS TSK
QSB RRF UBW
QXN SMQ
1.5 110 kW TSI RHR TSM TXU
SSP UAG
1.8 l/132 kW TFSI NKE PYV REU
PAX QAF RRG
PGP QRN SMW
PNC QHX SSW
Octavia III 2013 ➤, Octavia III 2014 ➤, Rapid NH 2013 ➤, Rapid NH 2014 ➤
Gearbox 0CW-DSG - Edition 07.2022
12 Rep. gr.00 - Technical data
