14 - Screw
❑ Gearbox mount to gearbox console
❑ Replace after removal
❑ 60 Nm + 90°
15 - Screw
❑ Gearbox mount to body
❑ ⇒ Rep. gr. 10; Assembly mountings; Removing and installing engine bracket
16 - Gearbox mount
❑ removing and installing ⇒ Rep. gr. 10; Assembly mountings; installing and removing engine bracket
17 - Gearbox bracket
❑ Assignment ⇒ Electronic Catalogue of Parts.
18 - Screw
❑ Gearbox bracket to gearbox
❑ Replace after removal
❑ 40 Nm + 90°
4.1.2 Summary of components - assembly bracket, Rapid
Octavia III 2013 ➤, Octavia III 2014 ➤, Rapid NH 2013 ➤, Rapid NH 2014 ➤
Gearbox 0CW-DSG - Edition 07.2022
4. Assembly bracket 223
