NOTICE
There is a risk of damage to the mechatronics for double
clutch gearbox -J743-.
In the event of oil loss from mechatronics, the correct oil level
can only be adjusted by changing the oil.
The oil level cannot be checked.
An insufficient amount of hydraulic oil and overfilling affect the
function of the mechatronics, this can lead to malfunctions.
– Carry out oil-tight sealing of the mechatronics ⇒ page 225 .
This avoids unwanted loss of oil when installing the mechatron‐
ics.
– Install mechatronics ⇒ a1.2 nd installing mechatronics”,
page 59 .
Tightening torques and summaries of components
Note
Replace bolts/nuts that are tightened at an angle of rotation, as
well as replacement components after removal.
♦ Oil drain and oil filling plug for mechatronics ⇒ o1.1 f compo‐
nents - mechatronics”, page 56
7.2.2 Drain hydraulic oil for mechatronics
(built-in mechatronics, for TPI purpo‐
ses)
Note
♦
This workflow is only used for mechatronic repairs that are
described in TPI 2066030 or TPI 2063136 and in which the
hydraulic oil is drained and filled on the installed mechatron‐
ic. The oil is drained through the lower drain hole.
♦
The mechatronic repairs described in this workshop manual
are carried out on the dismantled mechatronic. With these
repairs, the oil is drained from the mechatronics via the up‐
per drain plug after the mechatronics have been removed.
The workflow is described in chapter ⇒ a7.2.1 nd top up
hydraulic oil for mechatronics (dismantled mechatronics)”,
page 233 .
Special tools and workshop equipment required
Octavia III 2013 ➤, Octavia III 2014 ➤, Rapid NH 2013 ➤, Rapid NH 2014 ➤
Gearbox 0CW-DSG - Edition 07.2022
236 Rep. gr.34 - Controls, housing
