3.3 Installing the gearbox
⇒ g3.3.1 earbox, Octavia III”, page 211
⇒ g3.3.2 earbox, Rapid”, page 215
3.3.1 Installing gearbox, Octavia III
Required special tools are identical to the section called Re‐
moving the gearbox ⇒ t3.2 he gearbox”, page 158 .
Installation is performed in the reverse order, pay attention to
the following points:
• Renew self-locking nuts and bolts.
• Replace screws which have been tightened to a torquing
angle as well as sealing rings and seals.
• Secure all hose connections with hose clamps which comply
with the series design ⇒ Electronic Catalogue of Original
Parts.
• All cable straps that are detached or cut when removing
should be attached again in the same place when installing.
• Check whether the dowel sleeves for centring the gearbox
are present in the cylinder block, insert if necessary. The
housings are at the positions -A-.
– Clean the serration of the driveshaft and the serration of the
torsional absorber, remove corrosion, and only apply a thin
layer of grease onto the serration. Remove excess grease.
Lubricating grease assignment ⇒ Electronic Catalogue of Origi‐
nal Parts.
– Replace needle bearing -arrow- in the crankshaft ⇒ Rep.
gr. 13; Crankshaft; replace needle bearing in the crankshaft.
Octavia III 2013 ➤, Octavia III 2014 ➤, Rapid NH 2013 ➤, Rapid NH 2014 ➤
Gearbox 0CW-DSG - Edition 07.2022
3. Removing and installing the gearbox 211
