❑ is removed and installed together with the small engaging lever Pos. 12 and guide bushing upper part
- Pos. 11
15 - Sealing ring
❑ for inner drive shaft
❑ replace ⇒ g2.5 asket ring for inner drive shaft”, page 53
16 - Sealing ring
❑ for outer drive shaft
❑ replace ⇒ i2.4 nput shaft sealing ring”, page 51
2.2 Remove double clutch
Special tools and workshop equipment required
♦ Hooks -3438-
♦ Extractor -T10373A-
♦ Extractor -T10323-
Octavia III 2013 ➤, Octavia III 2014 ➤, Rapid NH 2013 ➤, Rapid NH 2014 ➤
Gearbox 0CW-DSG - Edition 07.2022
40 Rep. gr.30 - Clutch
