11 - Gearshift lever
12 - Screw
❑ 15 Nm
13 - Selector lever control cable
❑ Remove and install ⇒ a2.5 nd installing the selector lever control cable”, page 124
❑ testing and adjusting ⇒ a2.7 nd adjusting the selector lever control cable”, page 141
14 - Lock washer
❑ Replace after removal
15 - Screw
❑ Adjusting screw for selector lever control cable
❑ 12 Nm
2.1.2 Summary of components - gearshift mechanism, Rapid NH, - vehicles to
05.2015
Octavia III 2013 ➤, Octavia III 2014 ➤, Rapid NH 2013 ➤, Rapid NH 2014 ➤
Gearbox 0CW-DSG - Edition 07.2022
94 Rep. gr.34 - Controls, housing
