5. Switch check (2)
Page 2 Address 5C to 62
Using method:
1) Select page: 2, address: 5C to 62.
2) By discriminating the display data, the pressed key can be
discriminated.
6. Record of Use check
Page 2 Address 35 to 3D
Using method:
1) The record of use data is displayed at page: 2, addresses: 35 to
3D. Note: This data will be erased when the coin lithium battery
(LI-64 board) is removed (reset).
Address
35
36
37
38
39
3A
3B
3C
3D
Function
Minutes
Drum rotation counted time (BCD code) Hour (L)
Hour (H)
Year
User initial power on date (BCD code) Month
Day
Final condensation occurrence date
Year
(BCD code)
Month
Day
Remarks
10th place digit and 1st place digit of counted time (decimal digit)
1000th place digit and 100th place digit of counted time (decimal digit)
After setting the clock, set the date of power on next.
Address
5C
K AD IN 0
IC2302 *ª
5D
K AD IN 1
IC2302 (º
5E
K AD IN 2
IC2302 (¡
5F
K AD IN 3
IC2302 (™
60
K AD IN 4
IC2302 (£
61
K AD IN 5
IC2302 (¢
62
K AD IN 6
IC2302 (∞
00 to 1A
STOP
FK-4850
block
PAUSE
FK-4850
block
FADER
FP-657 board
S2
PROGRAM AE
CF-4850
block
DISPLAY
KY-39 board
S7831
16 : 9 WIDE
KY-39 board
S7832
LCD BRIGHT +
BV-4850
block
1B to 4A
REW
FK-4850
block
FF
FK-4850
block
BACK LIGHT
FP-657 board
S1
EXPOSURE
CF-4850
block
END SEARCH
KY-39 board
S7827
DATA CODE
KY-39 board
S7828
LCD BRIGHT –
BV-4850
block
4B to 7A
PLAY
FK-4850
block
LASER LINK
FK-4850
block
PICTURE EFFECT
KY-39 board
S7829
EXECUTE
CF-4850
block
TITLE
KY-39 board
S7825
VOLUME +
BV-4850
block
7B to AD
EDIT SEARCH +
FK-4850
block
FOCUS INFINITY
CF-4850
block
MENU
KY-39 board
S7822
5SEC REC
KY-39 board
S7823
VOLUME –
BV-4850
block
AE to DF
REC
FK-4850
block
EDIT SEARCH –
FK-4850
block
FOCUS AUTO
CF-4850
block
PANEL OPEN
FP-649 board
S1
PUSH REC
KY-39 board
S7823
PANEL NORMAL
FP-649 board
S2
E0 to FF
No key input
No key input
No key input
FOCUS MANUAL
CF-4850
block
PANEL CLOSE
FP-649 board
S1
NORMAL REC
KY-39 board
S7823
PANEL NORMAL
FP-649 board
S2
Data
To Next Page
