1. In “Panel/PQ” service mode
a. Go to “WB/Mura/CUC data transfer” category
by “↑” or “↓”.
b. To select “WB/Mura/CUC data transfer”,
press → button.
c. To change data , press “←” or “→” on remote
commander.
Please apply if Main board or panel is replaced.
2. In “WB/Mura/CUC data transfer”
a. Select “WB/Gamma data transfer” by pressing
“↑” or “↓” on remote commander .
b. To change the items, press “←” or “→” on
remote commander and press “Enter” button.
Selectable items are:
• 0. SoC to T-con
• 1. T-con to SoC
• 2. Not action
c. Similarly, to select the items in Mura and CUC
data.
d. Select “[start]” and press “Enter” button to start
transfer.
>>
>>
>>
>>
>>General Setting
Tuner
Wi-Fi / BT
Service Mode
Model Information
Self diagnosis History
Video / Audio
Panel / PQ
SDB Service Menu
[</>] Set [Home]Exit
>>
>>
>>
<<
>>
>>
Panel / PQ
Back
WB Adjustment
WB/Mura/CUC data transfer
[</>] Set [Home]Exit
<<
<[ 0.Soc to T-con ]>
Back
WB / Gamma data transfer
[</>] Set [Home]Exit
<[ 0.Soc to T-con ]>
Mura data transfer
<[ 0.Soc to T-con ]>CUC data transfer
Start
SERVICE ADJUSTMENT
WB/MURA/CUC Data Transfer
