SAFETY NOTES SELF DIAGNOSIS FUNCTION TROUBLESHOOTING SERVICE ADJUSTMENT DIAGRAM HANDLING GUIDE
1.3 No Power DDCON/LDO (LDO Check)
TROUBLESHOOTING
Check item summary
Check Enable pin
voltage
Is voltage >3V?
1.2 No Power U-Com Failure
or
Enable source
no
START
yes
Change LDO IC
Check Vcc voltage
C815
Is voltage >3.2V?
Check 3.3V_DDC_OUT
DDCON
(IC607 on BM5A)
or
3.3V_STBY (Power board)
no
yes
yes
Board Operation IC Ref Voltage supply
BM5A LDO IC809 3.3V_M5_STBY
SYSSET
2022/04/1901:21:05(GMT+09:00)
