68
SAFETY NOTES SELF DIAGNOSIS FUNCTION TROUBLESHOOTING SERVICE ADJUSTMENT DIAGRAM HANDLING GUIDE
TROUBLESHOOTING
4.3 Input Skip Function
Under default condition;
If user insert analog video cables into video jacks, the Video/Component will be highlighted and can be selected.
The detection mechanism is based on below tables.
Destination Input Signal
Non-Detect
(Typical)
Detect
(Typical)
WW
/EU
VIDEO IN
/AV IN
VIDEO_DET
IC1000 AH9-GPIO56
0V 3.3V
SYSSET
2022/04/1901:21:05(GMT+09:00)
