TROUBLESHOOTING
4.4 No Picture at Tuner - FOR DIGITAL TUNING For TW, NA-ATSC(MX/UC)
*1
, CH/HK, LA, PA
Notes:
- Parts for IF_N line : C3011
- Parts for IF_P line : C3010
- Parts for TAGC line: R3024, C3023, R3003,
: Insert correct signal in correct ANT terminal.A
*1:except US ATSC3.0, Please refer Digital Tuning 2
Sound is normal?
OK
No sound
Check part mounting condition
for digital data line
“IF_N, IF_P, TAGC”
Replace main board
Digital Tuning 1
OK
Change NG parts
Confirm ANT or Cable connection
For LA (Dual ANT)
For TW,NA-ATSC(MX/UC)
*1
,
CH/HK, PA, EU
NG
A
NG
OK
Replace main board
Replace tuner module
End
OK
NG
SYSSET
