Sony KD-43X85K User Manual

13
SAFETY NOTES SELF DIAGNOSIS FUNCTION TROUBLESHOOTING SERVICE ADJUSTMENT DIAGRAM HANDLING GUIDE
Self Diag. Quick Reference (Not LED blinking [Record Only])
Error Item FH
TCON ERR <T> T-CON device I2C communication failure
AUD_ERR_I2C <B> Audio amp I2C communication failure
TEMP_ERR_I2C <B/H> Temp sensor I2C communication failure
TU_DEMOD_I2C <B> Tuner & Demodulator I2C communication failure
<G>: Power Supply board, <B>: Main board, <T>: T-con board, <LD>: LD board, <Tu>: Tuner board, <A>: Power Adapter, <P>: Panel module, <S>: Speaker, <H>: H-board
SELF DIAGNOSIS FUNCTION
SYSSET
2022/04/1901:21:05(GMT+09:00)

Sony KD-43X85K Specifications

General

Screen Size	43 inches
Resolution	3840 x 2160 (4K UHD)
Display Type	LCD
HDR	Yes
Refresh Rate	120 Hz
Smart TV	Yes
Operating System	Google TV
HDMI Ports	4
USB Ports	2
Wi-Fi	Yes
Bluetooth	Yes
HDMI 2.1	Yes
Ethernet Port	Yes
Processor	4K HDR Processor X1
HDR Format	Dolby Vision, HDR10, HLG
Weight	10.7 kg (with stand)
