2.1 LED Blinking: 3x (DC ALERT)
TROUBLESHOOTING
3-time blinking
(DC Alert)
Check “5V_MAIN”
at JL601 on BM5A/BM5ST board,
4.75V < Voltage < 5.25V?
OK
NG
IC600, etc
(BM5A/BM5ST Board)
Check “12.7V_MAIN”
at pin 5,6,7,8 of CN1700 on
BM5A/BM5ST board,
Voltage = 12.2~13.2V?
BM5A
NG
Power Board
OK
Check Audio
Error
Check “5V_DET”
at CL1247 on BM5A/BM5ST board,
0.77V < Voltage < 1.11V?
OK
NG
R1284, R1285, etc
(BM5A/BM5ST Board)
SYSSET
