30
SAFETY NOTES SELF DIAGNOSIS FUNCTION TROUBLESHOOTING SERVICE ADJUSTMENT DIAGRAM HANDLING GUIDE
Board View
TROUBLESHOOTING
Top Side
3.3V_DDC_OUT
1.0V_TU_P
B-Side
5.0V_STBY_H
3.3V_MAIN_H
1.1V_M5_DDR
0.9V_M5_STBY
1.8V_STBY
0.8V_M5_CORE
1.8V_M5
1.0V_M5
0.8V_M5_GPU
0.8V_M5_CPU
1.8V_M5_ET_STBY
3.3V_M5_STBY
1.8V_EMMC
B Side
5.0V_VBUS/5V_
MAIN/5V_AUDIO
SYSSET
2022/04/1901:21:05(GMT+09:00)
