88
SAFETY NOTES SELF DIAGNOSIS FUNCTION TROUBLESHOOTING SERVICE ADJUSTMENT DIAGRAM HANDLING GUIDE
TROUBLESHOOTING
6.3 Wi-Fi Bluetooth - Bluetooth malfunction
Bluetooth Remote doesn’t work
Or
Bluetooth Mouse/Keyboard/Controller doesn’t work
Or
Bluetooth Speaker/Headphone/ doesn’t work
Please refer connection instruction
or device manual
OK
Loose FFC 20P
NG
OK
NG
NG
Change BM5A board
Wi-Fi/BT module
OK
NG
FFC 20P
OK
NG
Check FFC 20P
connection is OK between
Wi-Fi/BT module and BM5A
board
Change
Wi-Fi//BT module
“Settings”
“Remotes & Accessories”
“Bluetooth Settings”
(“Bluetooth” turn ON)
Connect properly
Change FFC 20P
Between BM5A board
and Wi-Fi/BT module
OK
FH
BM5A
Wi-Fi/BT modules
DHUR-SY63
FFC 20P
SYSSET
2022/04/1901:21:05(GMT+09:00)
