91
SAFETY NOTES SELF DIAGNOSIS FUNCTION TROUBLESHOOTING SERVICE ADJUSTMENT DIAGRAM HANDLING GUIDE
TROUBLESHOOTING
6.4 Built in Mic Malfunction (WW)
Bboard
FFC 25P
Receiver
Board
Main board: BM5A
Receiver board: HT2
Built in mic
doesn’t work
Mic hardware switch ⇒ On
Check Mic hardware
switch on TV
NG
Change FFC Cable
between Main board
and Receiver board
NG
OK
Connect
properly
OFF
OK
Check harness connection
between Main board
and Receiver Board
Change Receiver
board
OK
NG
Change Main board
SYSSET
2022/04/1901:21:05(GMT+09:00)
