SAFETY NOTES SELF DIAGNOSIS FUNCTION TROUBLESHOOTING SERVICE ADJUSTMENT DIAGRAM HANDLING GUIDE

TROUBLESHOOTING

4.4 No Picture at Tuner - FOR ANALOG TUNING

Notes:

- Parts for IF_N line : C3011

- Parts for IF_P line : C3010

- Parts for TAGC line: R3024, C3023, R3003,

: Insert correct signal in correct ANT terminal.A

Enable to broadcast

channels?

Analog Tuning

For LA only

For Other destination

Change NG parts

Replace main board

Confirm ANT or Cable connection

Check part mounting condition

for analog control line

“IF_N, IF_P, TAGC”

Replace main board

Replace tuner module

End
