Sony MVS-6520 User Manual

USO RESTRITO
148
Copy and Swap
Target bank
Target keyer
Target data
M/E-1
Keys 1 to 4
Key settings excluding
the following data
items:
• Setup data
• Key snapshots
• Key memory
PGM/PST
Downstream
keys 1 to 4
Target bank
Target keyer
Target data
M/E-1
Keys 1 to 4
DME wipe settings in
(MVS-6520/
the independent key
6530/3000A)
transition control
Keys 1, 2 (MVS-
block.
3000)
PGM/PST
Downstream
keys 1 to 4
(MVS-6520/
6530/3000A)
Downstream
keys 1, 2 (MVS-
3000)
Target bank
Target keyer
Target data
M/E-1
Keys 1 to 4
Wipe settings in the
independent key
transition control
block.
PGM/PST
Downstream
keys 1 to 4
Target bank
Target keyer and data
M/E-1
PGM/PST
Keys 1 to 4 and
downstream
keys 1 to 4
in each block
• Colors 1 and 2 for
key fill
• Colors 1 and 2 for
key edge fill
a)
• “Zabton” color data
a)
Colors 1 and 2 for wipe border
Color data for preset color mix
Color
background
• Colors 1 and 2 for color background 1
• Colors 1 and 2 for color background 2
DME ch1, ch2,
ch5 to ch8
b)
• Background
• Border
• Sepia
• Light
c)
• Drop shadow
• Trail
Target bank
Target data
M/E-1
PGM/PST
DME wipe settings.
However, it is not possible to carry out
copy or swap involving independent key
transition DME wipe settings.
Chapter
8
Color
Backgrounds,
Copy
and
Swap,
and
Other
Settings
Notes
If a DME is being used on the source keyer for a copy or
either keyer for a swap, then if for example there are
insufficient DME channels, or the limit on using DME
channels within an M/E bank is exceeded, it may not be
possible to select the DME.
Wipe copy and wipe swap
You can copy and swap the wipe settings among the banks
as follows.
Target bank
Target data
M/E-1
PGM/PST
Wipe settings.
However, it is not possible to carry out
copy or swap involving independent key
transition wipe settings.
Wipe copy and wipe swap in the
independent key transition control block
You can copy and swap the wipe settings among the
following keyers.
DME wipe copy and DME wipe swap
You can copy and swap the DME wipe settings among the
banks as follows.
DME wipe copy and DME wipe swap in the
independent key transition control block
You can copy and swap the DME wipe settings among the
following keyers.
Matte data copy and swap
You can copy or swap the matte data among the following
color generators.
Target bank
Target keyer and data
M/E-1
PGM/PST
Keys 1 to 4 and
downstream
keys 1 to 4
in each bank
• Matte data for key fill
• Matte data for key
edge fill
a)
Matte data for wipe border edge
Color
background
• Matte data for color background 1
• Matte data for color background 2
a) Only among keyers that support resizer and key edge.
Color data copy and swap
You can copy or swap the color data among the following
color generators.
• Shade
d)
a) Only among keyers that support resizer and key edge.
b) DME ch1 and ch2 are enabled when using the MKS-6570 only. DME ch5
to ch8 are enabled when using the MVE-8000A/9000 only.
c) Not possible for DME ch2 in an HD system.
d) Not displayed for DME ch5 to ch8.
