USO RESTRITO
26
Names and Functions of Parts of the Control Panel
Chapter
2
Names
and
Functions
of
Parts
Names and Functions of
Parts
Chapter
2
Names and Functions of Parts of the Control Panel
Specification differences for each system
configuration
In an MVS system, the number of available banks and keys
will differ depending on the control panel and switcher
processor configuration.
Name
ICP-6520 Control Panel
ICP-6530 Control Panel
ICP-3000 Control Panel
ICP-3016 Control Panel
Panel
configuration
Two rows
Three rows
Two rows
Two rows
Banks
M/E-1, PGM/PST
M/E-1, M/E-2, PGM/PST
M/E-1, PGM/PST
ME-1, PGM/PST
Keys
• When MVS-6520/
3000A/3000 (2M/E
processor) is
connected:
M/E-1: Key1 to Key4
P/P: DSK1 to DSK4
• When MVS-6530 (3M/E
processor) is
connected:
M/E-1: Key1 to Key4
P/P: DSK1 to DSK8
• When MVS-6520/
3000A/3000 (2M/E
processor) is
connected:
M/E-1: Key1 to Key4
P/P: DSK1 to DSK4
• When MVS-6530 (3M/
E processor) is
connected:
M/E-1, M/E-2: Key1 to
Key4
P/P: DSK1 to DSK8
• When MVS-6520/3000A/3000 (2M/E processor) is
connected:
M/E-1: Key1 to Key4
P/P: DSK1 to DSK4
• When MVS-6530 (3M/E processor) is connected:
M/E-1: Key1 to Key4
P/P: DSK1 to DSK8 (DSK5 to DSK8 insertion and
removal control from Flexi Pad)
This manual describes operations and settings for an MVS-
6520/3000A and ICP-6520 configuration as an example.
For details about operational differences resulting from
different specifications, 1 “8-Keyer Operation” (p. 412).
