Overview of Keyframes 243
Item
Paths that can be set
Key1 to Key4
Overall path settings for items
relating to keys 1 to 4 are made
simultaneously.
Key1 All to
Key4 All
Source
Key source path for keys 1 to 4
Fill
Key fill path for keys 1 to 4
Proc
Proc path for keys 1 to 4
Trans
Transition path for keys 1 to 4
Bkgd/Util
Overall path settings for items
relating to the background and
utility buses are made
simultaneously.
Bkgd/Util All
Bkgd A
Path for background A
Bkgd B
Path for background B
Util 1
Path for utility
DME 2nd
Video
a)
Path for video to be used for
second DME channel
Wipe/DME Wipe
Overall path settings for items
relating to wipes and DME wipes
are made simultaneously.
Wipe/DME
Wipe All
Wipe
Path for wipes
DME Wipe
Path for DME wipes
Trans
–
Transition path for each M/E and
PGM/PST bank
Item
Paths that can be set
3D Trans Local All
Overall path settings for local
channel three-dimensional
transform items are made
simultaneously.
Loc Size
Overall path settings for items
relating to image size changes and
movement are made
simultaneously.
Loc Size All
Size
Path for image size
Post Loc X,
Post Loc Y
Paths for movement in the X- and Y-
axes
Post Size
Path for size
Loc XYZ
Overall path settings for items
relating to image movement are
made simultaneously.
Loc XYZ All
Loc X, Loc Y,
Loc Z
Paths for the X-, Y- and Z-axes
Rot
Overall path settings for items
relating to image rotation are made
simultaneously.
Rot All
Rot X, Rot Y,
Rot Z
Paths for the X-, Y- and Z-axes
Spin
Overall path settings for items
relating to spin are made
simultaneously.
Spin All
Spin Src X,
Spin Src Y,
Spin Src Z
Paths for the X-, Y- and Z-axes
Spin X, Spin
Y, Spin Z
Paths for the X-, Y- and Z-axes
Asp
Overall path settings for items
relating to aspect ratio are made
simultaneously.
Asp All
Rate X, Rate
Y
Paths for movement in the X- and Y-
axes
Skew
Overall path settings for items
relating to skew are made
simultaneously.
Skew All
Skew X,
Skew Y
Paths for movement in the X- and Y-
axes
Aspect
Path for aspect ratio
Pers
Overall path settings for items
relating to perspective are made
simultaneously.
Pers All
Pers X, Pers
Y, Pers Z
Paths for the X-, Y- and Z-axes
Axis Loc
Overall path settings for items
relating to image rotation axis are
made simultaneously.
Axis All
Axis X, Axis
Y, Axis Z
Paths for the X-, Y- and Z-axes
Chapter
12
Keyframes
Paths relating to DME
DME 3D Trans Local menu
a) MVS-6520/6530/3000A only
User1 to User8 menus
The items that can be adjusted depend on the settings in the
Setup menu.
For details, 1 “Setting User Regions” (p. 346).
Item
Paths that can be set
User1 All to User8
All
Overall path settings for the
following items for each “User” are
made simultaneously.
FM Still Store
Overall path settings for frame
memory freeze image output are
made simultaneously.
FM Still
Store All
FM Still
Store 1 to 8
Paths for frame memory freeze
image outputs 1 to 8
Aux
Overall path settings for AUX buses
are made simultaneously.
Aux All
Aux 1 to 24
Paths for AUX 1 to 24
Color Bkgd
Overall path settings for color
backgrounds are made
simultaneously.
Color Bkgd
All
Color Bkgd 1
Paths for color background 1
Color Bkgd 2
Paths for color background 2
