USO RESTRITO
Power Supply and Connectors 55
Chapter
2
Names
and
Functions
of
Parts
Define the types of the connected devices on the control
panel.
i
MVS (multi format video switcher) connector
(RJ-45 compliant)
Connect to an ICP-series control panel. Connect to an
Ethernet switch
1)
if connecting a DCU, MVE-8000A/9000
multi format DME processor, and other devices.
j
UTIL (SW) (utility (SW)) connector (RJ-45
compliant)
Intended for future expansion.
k
REF INPUT (reference video input)
connectors
(BNC-type)
If you wish to synchronize this unit to an external reference
signal, input the reference signal. For an HDTV system,
input an HD tri-level sync signal, black burst signal, or
analog sync signal. For an SDTV system, input a black
burst signal or analog sync signal.
The two connectors have a loop-through configuration.
Signal input to one connector can be output from the other
connector. If you will not be using the loop-through
output, be sure to terminate the unused connector with the
supplied 75 ohm terminator.
l
TALLY/GPI IN (tally/ general purpose interface
input) 1 to 18 and TALLY/GPI OUT (tally/ general
purpose interface output) 1 to 48 connectors (D-sub
25-pin)
Output tally data created with the control panel of the MVS
system (open collector). These connectors can also be used
as GPI output ports.
You can also input trigger signals as GPI inputs.
Input and output settings are made on the control panel of
the MVS system.
m
SERIAL TALLY connector
(D-sub 9-pin,
RS-422A)
Output tally data created with the control panel of the MVS
system.
n
OUTPUTS
1 to 16 connectors (BNC-type): MVS-6520/
MVS-3000A/
MVS-3000
1 to 32 connectors (BNC-type): MVS-6530
These connectors output serial digital signals. You can
assign them as program output, preview output, AUX
output, and so on.
Make output assignments on the MVS system control
panel.
For details about assignable signals,
1
“Signal Output
Settings” (p. 351).
o
PRIMARY INPUTS
1 to 32 connectors (BNC-type): MVS-6520/
MVS-3000A/
MVS-3000
1 to 48 connectors (BNC-type): MVS-6530
These connectors allow you to input up to 32 or up to 48
serial digital video signals to the MVS-6520/MVS-3000A/
MVS-3000 or MVS-6530, respectively.
1)
For information about devices that can be connected, contact your Sony
representative.
