Chapter
3
Signal
Selection
and
Transitions
If, in the Setup menu, you set insertion/deletion as
independent modes, you can set the transition rates for key
insertion and deletion independently. For example, with
the system in the state with the key not inserted, the
transition rate setting applies to key insertion.
This section describes setting an independent key
transition for key 1 on the M/E-1 bank, as an example.
Setting the independent key transition rate
in the Flexi Pad
1
In the Flexi Pad, press the [TRANS RATE] button.
The Flexi Pad switches to the transition rate setting
mode.
2
In the region selection buttons, select the switcher
bank.
3
Press the [TRNS SEL] button in the memory recall
section.
You can select the type of transition for which to set
the rate.
4
Press the [KEY1] button.
This enables setting of the independent key transition
rate for key 1 of the M/E-1 bank.
5
While viewing the alphanumeric display, enter the
transition rate you want to set with the memory recall
section button.
If required, press the [TC] button to toggle the input
mode (frame input or timecode input).
•
Enter a value of up to three digits.
•
To cancel the input, press any of the mode selection
buttons.
6
Press the [ENTR KEY1] button.
Setting the independent key transition rate
by a menu operation
1
Open the M/E-1 >Key1 >Transition menu (1116).
2
Select any transition type in the <Transition Type>
group.
If, in the Setup menu, you set insertion/deletion as
independent modes, make the settings for insertion in
the <On Transition Type> group, and the settings for
deletion in the <Off Transition Type> group.
3
Set the transition rate.
Displaying the independent key transition
rates in a menu and changing the settings
For each of the banks, you can display the transition rate,
independent key transition rate and fade-to-black
transition rate, and change the settings
(
1
p. 150).
Fade-to-Black
This function gradually darkens the program output video
of the PGM/PST bank, eventually cutting it to black.
Notes
•
In multi-program mode, it is possible to carry out a fade-
to-black on a number of programs simultaneously.
•
Fade-to-black can be executed via GPI or a macro. It
cannot be executed from a control panel button.
You can also make a Setup menu setting such that a fade-
to-
black does not apply to particular programs.
For details about settings,
1
“Enabling or disabling the
fade-
to-black function” (p. 356).
Setting the fade-to-black transition rate
1
Open the PGM/PST >Misc >Transition menu (1471).
2
Select [FTB].
3
Set the fade-to-black transition rate.
Displaying the transition rates in a menu
and changing the settings
For each of the banks, you can display the transition rate,
independent key transition rate and fade-to-black
transition rate, and change the settings
(
1
p. 150).
